5207 5 rev. 09/16/20
PARTS LIST AND DRAWING
MODEL 5207
CAPACITY: 700 LBS.
ENGINE SUPPORT BAR
1 Support Beam (Large) 1
2 Support Beam (Small) 1
3 * "J" Hooks 2
4 * Wing Nut M12 1
5 * Hex Bolt M12 x 120 1
6 RS520706A Adjustable Pipe (incl. #14) 1
7 * Barrel Hex Nut 2
8 * Wing Nut M10 1
9 * Hex Bolt M10 x 55 1
10 Transfer Bar 1
11 Transfer Adapter 1
12 RS520712A 1/8" Braided Steel Wire (each) 2
13 RS70001 Foot with Sleeve, Black (set of 2) 1
14 Rubber Tip (incl. with #6) 1
N/S RS5207PLK Product Label Kit 1
Index No. Part No. Description Qty. Index No. Part No. Description Qty.
*Only available in Bolt Kit, Part #RS5207BKA.
Only Index No.'s identified by Part No. are available separately.
