17
Specications
Amplier Output
520 watts rms into 4Ω
High Cut Filter
40 Hz - 160 Hz adjustable, with an LFE
bypass position
12 - 36 dB/octave adjustable slope
Frequency Response
33 Hz - 150 Hz (-3 dB)
Power Line Voltage
US model
120 VAC 50/60 Hz
International model
230 VAC 50/60 Hz
Dimensions
(H x W x D)
1.75" (1U) x 19" x 11.2"
44.5 mm x 482.6 mm x 284.5 mm
Weight
13.5 lb. (6.12 kg)
AC Line Power Consumption:
75 watts average, 0.5 watts in standby
815 watts maximum
Output Levels:
Greater than 106 dB peak SPL (includes
room gain) Measurement is at 1 meter,
anechoic
Total Harmonic Distortion (amplier):
Less than 0.5% at 500W into 4Ω
Input Sensitivity (full output):
23 mV rms at 38 Hz with volume control
set to maximum
Input Impedance:
49 kΩ for Line-Level input
20 kΩ for XLR input
XLR Input
Pin 1 Ground
Pin 2 Positive
Pin 3 Negative
12 VDC Trigger Input
Input voltage range: 2.2 -13 VDC
Impedance: approx 2800Ω
(4.2 mA @ 12 V)
3.5 mm mono minijack, tip positive.
© 2012 Sunre Corporation.
All rights reserved. Sunre Corporation
reserves the right to improve its products
at any time. Therefore, specications are
subject to change without notice.
Manual 9901231 Rev A
