Sungrow PVS-16MH User Manual

User Manual 9 Appendix
47
Model
PVS-16MH
PVS-20MH
PVS-24MH
RS485 communication port
Standard
9.2 Cable Requirement
Model
PVS-16MH / PVS-20MH / PVS-24MH
Input cable
Type: MC4 terminals or 4~6mm
2
, stranded flame-retarded copper
wire
Stripped length:10mm
Bolt: M4
Tightening torque: 1.8N.m
Output cable
Type: 120~400mm
2
flame-retarded wire
Stripped length: 35mm
Communicatio
n cable
Type: 2×1.5mm
2
(outer diameter: 5mm~10mm) four core STP
with low resistance
Stripped length:7mm
Grounding
terminals
Type: 10mm~14mm (outer diameter), stranded flame-retarded
copper wire
Stripped length: 15mm or 25mm
Bolt: M5 or M8
Tightening torque: 4.4±0.4N.m or 20.5±2.5N.m
9.3 Quality Assurance
Where any fault occurs during the warranty period, Sungrow will maintain or
replace the product for free.
Evidence
Sungrow Power Supply Co., Ltd. needs the users to provide the receipt invoice
and the date you purchase. Meanwhile the trademark should be clearly legible.

Sungrow PVS-16MH Specifications

General

Brand	Sungrow
Model	PVS-16MH
Category	Controller
Language	English
