5 Electrical Installation
5.1 Internal Structure
There are two versions of the combiner box: version 1 and version 2. Taking
PVS-24MH as an example, the corresponding internal structures are as follows.
A
D
B C
E
F
G
Fig. 5-1 Version 1
