Sungrow SG20RT - Page 46

Inverter 1 Inverter 2 Inverter 5
A1
A1
B1
…
…
PC
Network port
A1
Logger
Ethernet
RS485
B1
B1
Refer to the manual of Logger for the communication connection to the meter.

(< 10 m)
(< 10 m)
Meter
Ripple control
1
2
8
4
TIA/EIA 568A
TIA/EIA 568B
7
Click
3
5
35 mm
5-6 N m
.
6
D1/5 D3/7
D2/6 D4/8 C
E + (2~3) mm
Peeling length of insulation layer:
Peeling length of protective layer:
40...50 mm
E
7...10 mm for single-strand wire
for multi-core multi-strand wire
For multi-core multi-strand wire
45
