Sungrow SG2K-S Quick User Manual

Quick User Manual 2 Installation
5
Self-tapping screw M6 Spring washerFender washerExpansion tube
1. Align the wall mounting bracket
horizontally on the wall with the
arrow upwards. Mark the
position of the drill holes. Use
at least one hole on the right-
and left-hand side of the wall
mounting bracket.
Tip: When mounting on a post,
use the upper and lower central
holes of the wall mounting
bracket.
2. Set the wall mounting bracket aside and drill the marked holes. The
depth of the holes should be about 70 mm. Install the wall-mounting
bracket.
Wall-mounting bracket
Fender washer
Spring washer
Self-tapping screw
Expansion tube
3. Mount the inverter to the bracket, and secure it with an M4x80 screw
(torque: 1.5 Nm).

Sungrow SG2K-S Specifications

General

Brand	Sungrow
Model	SG2K-S
Category	Inverter
Language	English
