Sunjoy A106005400 - Step 2 Assembly Procedures; Assembly Step 3; Hardware Pack 3 Details

5 / 8
Country of Origin: China
Hardware Pack 3
Fig.5:Attachtopbeam1（A）totopbeam2（B）,fixbyusingbolt（AA）andwasher（BB）.
Fig.6:Fixassembledtopbeam1/beam2(A/B)toassembledArcbeam1/Arcbeam2（C/D）,byusingbolt（EE）
andwasher(BB).
Fig.7:Attacharcsupport1（K）toshortsidebeam1/shortsidebeam2（C1/C2）,Arcsupport2（L）toArcbeam1/
Arcbeam2（C/D）andarcsupport1/Arcsupport2（L）topost1/post2（H1/H2）,byusingbolt（EE）andwasher
（BB）.
GG H010020014 M6 * 10 Bolt
4PCS
BB H050010023 M6 Flat Washer 4PCS
DD H010020024 M6 * 75 Bolt 8 PCS
FF H070010008
Φ6*230 floor stake
8 PCS
Fig.5
Fig.6
F1/F2
H1/H2
A/B
F1/F2
BB
EE
Step.3
Fig.8
Fig.10-1
Fig.10-2
Fig.9
Fig.
12
R
P
O
Q
M
A
B
H2
BB
AA
C/D
K
L
EE
BB
BB
EE
Fig.7
Fig.11
