To remove the bench, unmount the heater frames from the surrounding walls. Reach
underneath, with your palms upward, and the bench will lift straight up from the
supports mounted to the walls (for Discover and Empower cabins, you only need to
remove the back-wall bench sections). You can then rotate the detached bench vertically
and walk it backwards out of the sauna.
Step 2
The very last portions of the oor, under the bench and back against the wall, cover the power
box. Unscrew the power box covers. The Phillips head screws will be located in the grooves
between the oor boards. You will see the sections of the power box covers with a bisecting
cut perpendicular to the wood slats. Remove all screws for all sections of the power box covers.
Step 3
Once exposed, remove the Phillips screws anchoring the power box to the ground - two on the
long front edge and one on the right edge close to the back wall (as you are facing the back wall).
mPulse Power Box Installation Guide mPulse Power Box Installation Guide
Step 4
Disconnect the power cord on the left edge of the power box.
NOTE: The power cord is also anchored by a Phillips screw to the wood inside the base,
immediately to the left of the power box.
Step 5
We are now ready to begin disconnecting the power box from the wiring from the walls.
Start with the left wall connections. These will both be labeled with a triangle. Disconnect
the power feed, G1, from the wall feed, A1. Each connector has a lever on one side that you
press to pull them apart.
Step 6
Disconnect the L sensor connector, then disconnect the NIR connector. Finally, disconnect the
main power cord on the left side from the power box. You may need to remove the Phillips screw
anchoring the cord to the oor.
