SUNLU SL Series - Filament Support Installation

06
4.Filament Support Installation
Step1：Filament support spare parts shows in Pic 7.
Step2：Unwrap the support and put the M3 nuts into the slots which is circled(Pic 8).
Then connect with other two bigger boards with M3 screws(Pic 9 & Pic 10).
Step3：Load filament like Pic 11 and make sure the filament always loading from upside like Pic 12.
Pic7
Pic8
Pic9
Pic10
Pic11 Pic12
