Sunmax RT-50 - Clear Water Tank Components

10
Squeegee Lifting Components
Number Description Quant
ity
1
Bolt
1
2
Left Baffle
1
3
Pipe
1
4
Handle
1
5
Rear Baffle
1
6
Screw
2
7
Washer
1
8
Screw
1
9
Nut
1
10
Pad
3
11
Pull Rope
Components
1
12
Ring
1
13
Nut
1
14
Balancing Frame
1
15
Axis
1
16
Cotter Pin
1
17
Washer
1
18
Hinge Pin
1
19
AdjustmentBolt
1
20
Support Arm
1
21
Support Arm
1
22
Nut
1
23
Washer
1
24
Spring
1
25
Screw
1
26
Cotter Pin
1
27
Water
1
28
Hinge Pin
1
29
Adjustable Bolt
1
30
Adjustment
Device
1
31
Spring Pin
1
