ASSEMBLY INSTRUCTIONS
1. Remove the stepper mainframe from the box. Lift one pedal up first and check to
insure that the cable is properly secured around the wheel as shown in the picture
below.
2. Locate and adjust the Knob (2) to the desired setting level, turning the knob
clockwise "+" will increase tension and the stepping range making it higher, turning
the knob counter-clockwise "-" will decrease tension and the stepping range making
it lower.
3. Attach the Exercise Bands (3) to the pedal hooks located at the fronts of the left and
right pedals of the stepper
as shown in the picture below.
4. The assembly is completed!
