Sunny SF-E3865 - PARTS LIST

4
PARTS LIST
No.
Description
Spec.
Qty.
No.
Description
Spec.
Qty.
1
Main Frame
1
31
Bottom Cable
700mml
1
2
Upright Tube
1
32
Motor
TL-005
1
3
Fixed T Handle
Bar
1
33
Sensor
100mml
1
4L
Left Upper
Swing Bar
1
34
DC Cable
700mml
1
4R
Right Upper
Swing Bar
1
35
Adapter
TZ
1
5L
Left Lower
Swing Bar
1
36
Sensor Fixture
1
5R
Right Lower
Swing Bar
1
37
Motor Wire
150mml
1
6L
Left Pedal Tube
1
38L
Left Chain Cover
1
6R
Right Pedal
Tube
1
38R
Right Chain Cover
1
7L
Left Wheel Tube
1
39
Interior Chain
Cover
1
7R
Left Wheel Tube
1
40A
Swing Bar Cover-A
2
8
Crank Tube
2
40B
Swing Bar Cover-B
2
9
Rear Stabilizer
1
41A
Crank Tube Cover-
A
4
10
Front Stabilizer
1
41B
Crank Tube Cover-
B
4
11
Joint Bracket
2
42
Upright Tube Cover
1
12
Washer
Φ8*Φ38*2.0T
2
43A
Lower Swing Bar
Cover-A
2
13
Axle Fixed
Bracket
20*3t*55mm
2
43B
Lower Swing Bar
Cover-B
2
14
Magnet Bracket
30*5t*145mml
1
44
L Side Trim Cover
1
15
Magnet Position
Bracket
30*4
1
45
PU Wheel Cover
2
16
Gliding Track
40.67*655mm
2
46
Swing Axle Cover
2
17
Axle of Flywheel
20*164
1
47
Glider Track Cover
4
18
Belt Wheel Set
Φ260mm
+Φ19.05*232.1
1
48
PU Wheel
Ø100
2
19
Hex Socket Bolt
M8x50
2
49L
Left Pedal
1
20
Pedal Tube Axle
Ø19*161
2
49R
Right Pedal
1
21
Bushing
19.5*24*12.5
1
50
Bushing
9.5*34*32.5
2
22
Bushing
8.1*17*10.2
2
51
Bushing
10*32*2.5T
4
23
Flywheel
Ø460
1
52
Bushing
16.3*38*3T
4
24
HDR Grip
32*5T*940
2
53
Bushing
18.8*38
10
25
HDR Grip
32*3T*150
2
54
End Cap Oval
Dome
40*80
4
26
Belt
PK5 1180
1
55
End Cap Oval
40*80
1
27
Console
TZ-4113PMS
1
56
End Cap
Ø32
2
28A
Heart Rate Wire
500mm
2
57
End Cap
Ø50
2
28B
Heart Rate Wire
2
58
End Cap
Ø60
1
29
HR Sensor Plate
TZ TP-009
2
59
End Cap
Φ38*Φ29
2
30
Upper Cable
900mml
1
60
End Cap
Ø44
1
