SUNON UP 1 - Assembly: Electrical Connections (Power); Connecting Power and Adapter Cords

Page 12 of 23
R
L
A
M6x14
(x11)
D
ST5x16
(Optional)
(x2)
R
L
9
A
A
A
A
A
A
A
D
1. Put the Desktop Panel upside down on the ground, then put the desk frame on the Desk Panel.
2. Adjust the width of the Desk Legs to properly align the screws holes.
3. Fasten the Desktop Panel with 11 M6x14 hex screws.
4. Install the Manual Control Panel on the Desktop Panel and make sure the screw holes are properly
aligned, then fasten the 2 short ST5x1 self-tapping screws.
H
M4 Allen
Wrench
(x1)
