SUNON UP 1 - Assembly: Electrical Connections (Wiring); Wiring the Control System

1. Connect one end of the two Adapter Cords to the adapter interfaces at both sides of the Control Panel.
2. Connect the other end of the two Adapter Cords to the adapter interface on the top of the two Table Legs
respectively.
3. Connect the Power Cord to the power interface of the control panel.
E
Power Cord
(x1)
F
Power Cord
(x1)
F
F
8
Page 13 of 23
