SUNON UP 1 - Assembly: Optional Socket; Positioning Integrated Socket

Coiled Tube
(Optional)
(x1)
2
C
ST5x20
(Optional)
(x2)
Page 17 of 23
1
1
C
1. Install the Coil Tube on the Desktop Panel. Make sure the screw holes on the fix plate of
the Coiled Tube align with the screw holes on the Desktop Panel.
2. Fasten the Coiled Tube with 2 ST5x20 self-tapping screws.
