SUNON UP 1 - Assembly: Side Bracket Mounting; Mounting Side Brackets

R
B
M6x10
(x8)
B
B
Page 8 of 23
L
2
5
4
5
B
B
B
B
B
B
Fasten the 8 M6x10 hex screws with M4 Allen Wrench.
Note: If screws accidentally fall into the Assembly Frame, incline the Assembly Frame
and take out the screws.
H
M4 Allen
Wrench
(x1)
