Sunpak S34?TSR - Wiring and Power Adapter Installation

To Next Page

To Previous Page

Sunpak® Infrared Heaters



YoumustremovetheSunpakFaceTrimtoconnectpowertotheheater.TheSunpakFaceTrimis

attachedwithfour(4)screwslocatedalongeachsideoftheheater.



BasicWiring

SunpakS34‐TSRrequires7.5VDCforitscontrols.Inmost

casesyouwillberunninglowvoltagewirefromthePower

Adapterpluggedintoa120VACoutlet.ThePowerAdapter

isnotwaterproofandmustbeweatherprotected.The

extensionwirecanberun50feetwith18

GAandmusthave

suitableoutdoorinsulation.Inordertoaddtheextension

wireyoumust:

1. RemovetheFaceTrim

2. DisconnectthePowerAdapterfromthecontrol

module.

3. Attachtheslideconnectortotheextensionwire.

4. Connectoneendoftheextensionwirecabletothe

moduleandtheotherendtothePowerAdapter

WARNING:DonoattachtheExtensionCabledirectlyto

the120VACOutlet.

NOTE:MaleandFemaleconnectionsaresuppliedinthe

extensionkitsuppliedwitheachheater
