Sunpak S34?TSR - Sunpak Pilot and Electrode Adjustment

To Next Page

To Previous Page

Sunpak® Infrared Heaters

2. Locatethelearnbuttonoftheheatercontrolasshowninthediagramonpage3.Pressandhold

for6secondsbeforereleasing.

3. Pressandreleasethelearnbuttonontheheatercontrol.Pressthe<ON>buttononthewireless

devicewithin10seconds.

4. Theheatershould

nowrecognizethewirelessdevice.

a. Pressthe<OFF>buttononthewirelessdevice

b. Pressthe<ON>button

c. Pressthe<HI>button

d. LeaveheateronHIforfirst5minutes

Repeatprocedure4,ifheatersparkturnsON,buttheheaterdoes notlightup.Itis

likelythatthereis

stillairinthegasline.Iftheheaterfailstolightorfailstostaylitafterseveraltries,itmaybenecessary

tobleedthegasline.



Sunpak Pilot

The two electrodes near the pilot provide for

flame ignition and sensing. It is important that

these electrode be position properly.

• Electrodes should be located 3/16”from the

pilot hold within the flame zone.

• Electrodes must be space at least 3/8” from

each other to avoid spark electrode from

ground to the sensing electrode.

• The ‘L’ shaped electrode should always be

used for sensing


