SUNPOWERCORPORATION
SafetyandInstallationInstructions‐Document001‐14158RevAI


©2021SunPowerCorporation.Allrightsreserved.Specificationsincludedintheseinstructionsaresubjecttochangewithoutnotice.Page|2
SafetyandInstallationInstructions
(UnitedStatesandCanada)
1.0 Introduction
TheseinstructionsprovidesafetyandinstallationinstructionsforUL
ListedSunPowerphotovoltaic(PV)modulesthathavetheULlogoonthe
productlabel:



1.1DisclaimerofLiability
Theinstallationtechniques,handling,anduseofthisproductarebeyond
companycontrol.Therefore,SunPowerassumesnoresponsibilityforloss,
damageorexpenseresultingfromimproperinstallation,handling,oruse.

1.2UnderwritersLaboratories(UL)ListingInformation
ThisproductmeetsorexceedstherequirementssetforthbyUL1703,ULC/ORD‐
C1703‐01forPVModules,UL1741formoduleswith‐MLSDandUL61730forA‐
SeriesandM‐Seriesmodules.TheseStandardscoverflat‐platePVmodulesand
panelsintendedforinstallationonbuildingsorthoseintendedto
be
freestanding.TosatisfytheListingforthisproductthemodulesmustbemounted
witharackorstandoffstructure.TheListingdoesnotincludeintegrationintoa
buildingsurfacebecauseadditionalrequirementsmayapply.Thisproductisnot
intendedforusewhereartificiallyconcentratedsunlightisappliedtothemodule.


1.3LimitedWarranty
ModulelimitedwarrantiesaredescribedinfullintheSunPowerwarranty
certificatesobtainableatwww.sunpower.com.Insummary,theLimited
Warrantiesdonotapplytoanyofthefollowing:
ModuleswhichinSunPower'sabsolutejudgmenthavebeensubjectedtomisuse,
abuse,neglectoraccident;alteration;orimproperinstallation,applicationor
removal.Thisincludes,butisnotlimitedto,installation,application,orremoval
byanypartyotherthanaSunPowerauthorizeddealer;non‐observanceof
SunPower'sinstallation,user’sand/ormaintenanceinstructions;repairor
modificationsbysomeoneotherthananapprovedservicetechnicianof
SunPower;powerfailuresurges,lightning,flood,fire,accidentalbreakage,or
othereventsbeyondSunPower'scontrol. 
2.0 SafetyPrecautions
Beforeinstallingthisproduct,readallsafetyinstructionsinthisdocument.


 AllinstallationsmustbeperformedincompliancewiththeNationalElectrical
Code(NEC)andanyapplicablelocalcodes.
 ForCanadianjurisdictions,installationsshallbeinaccordancewithCSAC22.1,
SafetyStandardforElectricalInstallations,CanadianElectricalCode,Part1
 ModulescertifiedtoUL61730areSafetyClass2
forprotectionagainst
electricshock
 Therearenouser‐serviceablepartswithinthemodule.Donotattemptto
repairanypartofthemodule.
 Installationshouldbeperformedonlybyqualifiedpersonnel.
 Donotstandon,drop,scratch,orallowobjectstofallonmodulesasdoing
so
maydamagethemandvoidthewarranty.
 Donotplaceanythingonthemodules,evenforamomentbecauseresulting
residuemaydamageorstaintheglasssurface.
 Ifthefrontglassisbroken,orthebacksheetistorn,contactwithanymodule
surfaceormoduleframecan
causeelectricshock.
 BrokenJ‐boxesorconnectorsareelectricalhazardsaswellaslaceration
hazards.Installersshouldremoveanysuchmodulefromthearrayand
contactSunPowerfordisposalinstructions.
 Donotinstallorhandlethemoduleswhentheyarewetorduringperiodsof
highwind.
 Donotblockdrainholesorallowwatertopoolinornearmoduleframes.
 SunPowerrecommendsaconservativeminimumcablebendradiusofequal
toorgreaterthan
40mm(1.5”).
 Unconnectedconnectorsmustalwaysbeprotectedfrompollution(e.gdust,
humidity,foreignparticles,etc),priortoinstallation.Donotleave
unconnected(unprotected)connectorsexposedtotheenvironment.Aclean
assemblyenvironmentisthereforeessentialtoavoidperformance
degradation.
 Do not allow the connectors to come in
 contact with chemicals such as
greases,oilsandorganicsolventswhichmaycausestresscracking.
 Do not disconnect any modules when its inverter is feeding in to the grid.
Switchofftheinverterbeforedisconnecting,reinstallingormakinganyaction
withthemodules.
 Forconnectors, whichare accessible
tountrainedpeople,itisimperativeto
usethelockingconnectorsandsafetyclips,ifapplicable,inordertodefend
againstuntrainedpersonneldisconnectingthemodulesoncetheyhave been
installed.
 Cover all modules in the PV array with an opaque cloth or material before
makingorbreakingelectricalconne ctions.

 ContactSunPowerifmaintenanceisnecessary.
 Savetheseinstructions!

2.1FireRating
ThemodulefireratingisType2perUL1703,2013editionandClassCper
UL1703,2002edition.FireratingclassificationforanyPVsystemusing
UL1703:2013canonlyestablishafireratingincombinationwiththemounting
systemratingsnormallyfoundinthemountingsysteminstallationinstructions.
3.0 ElectricalCharacteristics
ElectricalcharacteristicsofthemodulesaredescribedinTable1below.Rated
electricalcharacteristicsarewithin10percentofmeasuredvaluesatStandard
TestConditionsof:1000W/m2,25°Ccelltemperatureandsolarspectral
irradianceperIEC60904‐3orirradiationof(airmass)AM1.5global(G)spectrum.
Eachmodule
containsthreebypassdiodes.Themaximumseriesfuserati ngis
15A;forA‐SeriesandM‐Seriesmodulesitis20A.
Undernormalconditions,aphotovoltaicmodulemayexperienceconditionsthat
producemorecurrentand/orvoltagethanreportedatStandardTestConditions.
Accordingly,thevaluesofISCandVOCmarked
onULListedmodulessh ould
alwaysbemultipliedbyafactorof1.25whendeterminingcomponentvoltage
ratings,conductorcapacities,fusesizesandsizeofcontrolsconnectedtothe
moduleoutput.RefertoSection690‐8oftheNECforanadditional1.25Safety
factorwhichmaybeapplicable.
DANGER!Moduleinterconnectioncablespassdirectcurrent(dc)and
aresourcesofvoltagewhenthemoduleisunderloadandwhenitis
exposedtolight.Directcurrentcanarcacrossgapsandmaycause
injuryordeathifimproperconnectionordisconnectionismade;or
ifcontactismadewithmoduleleadsthatarefrayedortorn.Donot
connectordisconnectmoduleswhenacurrentsourceisenergizing
theconductors.Modulesmaycontainhighvoltagewhen
interconnectedwithothermodules.
IMPORTANT!Pleasereadtheseinstructionsintheirentiretybefore
installing,wiring,orusingthisproductinanyway.Failuretocomply
withtheseinstructionswillinvalidatetheSunPowerLimited
WarrantyforPVModules.
