SUNPOWER CORPORATION
Safety and Installation Instructions - Document 001-14158 Rev AG
© 2020 SunPower Corporation. All rights reserved. Specifications included in this manual are subject to change without notice. Page | 7
Stacking Pins
4X Ø6.10 mm [.24in]
300 mm
[11.8in]
20X Ø6.8 mm
Mounting Holes
4X Ø4.2 mm [.17in]
Ground Holes
4X Ø4.8 mm [.19in]
Drain Holes
398 mm
[15.7in]
3.2 mm [.13in]
46 mm [1.8in]
(Front View)
(Back View)
1046 mm [41.2in]
1002 mm [39.4in]
2067 mm [81.4in]
1200 mm [47.2in]
1423 mm [60.4in]
539 mm [21.2in]
400 mm
[15.7in]
1058 mm [41.7in]
SLOT 5.0(W) X 15.0 (L)
Platform
Module mounting and ground hole detail
FOR COMMERCIAL (SILVER FRAME) MODULES ONLY, INCLUDES STACKING PINS
Commercial
Modules
96-CELL COMMERCIAL MODULE 128-CELL COMMERCIAL MODULE
1559 mm [61.4in]
1535 mm [60.4in]
1200 mm [47.2in]
1046 mm [41.2in]
1002 mm [39.4in]
(Back View)
(Front View)
915 mm [36.0in]
46 mm [1.8in]
3.2 mm
[0.13in]
398 mm
[15.7in]
4X Ø6.10 mm [0.24in]
Stacking Pins
6X Ø4.2 mm [0.17in]
Ground Holes
12X Ø6.6 mm [0.26in]
Mounting Holes
4X Ø4.8 mm [0.19in]
Drain Holes
SIDE FRAME PROFILE END FRAME PROFILE
With Stackings Pins
FOR COMMERCIAL (SILVER FRAME) MODULES
ONLY, INCLUDES STACKING PINS
FOR GEN 6 FRAME MODULE ONLY
1098 43.2
1002 39.4
1535 60.4
1200 47.2
915 36.0
12x Ø 6.80
(MOUNTING)
1559 61.4
1046
41.2
4x Ø 4.2 [.17]
(GROUND)
SIDE FRAME PROFILE END FRAME PROFILE SIDE FRAME PROFILE END FRAME PROFILE
With Stackings Pins
Method 1:
Frame Hole
Locations
Method 1:
Frame Hole
Locations
