Front Screen Installation
Crank Side
Idler Side
Center Roll Support
Image of 16’ / 20’ awning center support. Differ-
ent than 12’ awning support seen below.
STEP 1: ASSEMBLE OUTER BRACKETS - Duplicate crank side and idler side assembly
STEP 2: CENTER ROLL SUPPORT - Install on the center of front valance bar
STEP 3: INSTALLING OUTER BRACKETS - Remove end cap to expose track for bracket install
STEP 3: INSTALL ROLL SCREEN - Insert idler side first
To Next Page
