Sunshine SXJS3018 - Technical Parameters; Installation and Adjustment

- 4 -
SXJS3018 DOUBLE-DECK SCISSOR LIFT
The lift is including mechanical system, hydraulic system, pneumatic system
and electrical system as below:（Fig. 1）：
1. Pulling head 2. Platform 3. Machine arm
4. Above protection lock 5. Below protection lock 6. Hydraulic cylinder
7. Air cylinder 8. Base 9. Control box
Chapter 2. Technical Parameters
2.1 Main Technical Parameters：
2.2 Dimensional Schematic Diagram（Fig. 2）：
Chapter 3. Installation and Adjustment
3.1 Installation Environment
The lifts should be installed in the indoor environment without dust and other
pollution, and adequate lighting. Note the control cabinet should be placed in
secure area.
Model Lifting Height Lifting Weight
Hydraulic
Pressure
Pneumatic
Pressure
SXJS3018 2000mm 4000Kg 25Mp 0.4-0.6Mp
Lifting Time Power Motor power Dimension(mm)
≤90s 380/220V,50Hz 2.2Kw 1560x1900x2000
Fig. 2 Dimensions layout
