1) Sewing machine
8
1
Specification
Sewing speed
Stitch length
Needle
Hook
Needle bar stroke
Gap in height between main
and sub presser foot
Presser foot lift
Cylinder diameter
Motor
Model
Specification
KM-380BL
KM-390BL
Max. 2,200 spm
Max. 6mm
DP 17 18( 11~ 23) DP 17 23( 11~ 23)
Vertical large hook Horizontal large hook
34.2
2 5.5
By Hand 10mm/By Knee 15mm
50mm 77mm
250W 2P Clutch Motor
2
Installation
Warning
▶Installation of the machine should be performed by a trained engineer.
▶Any electrical wiring must be performed by a qualified technician or agent.
▶The machine weighs over 32kg. At least 2 persons should carry out the installing work.
▶Plug in after the installation is complete.
If the operator mistakenly steps down on the pedal with the pug in, the machine will start
automatically and can cause physical injuries.
▶Connect the ground (earth) wire.
An unstable connection may result in an electric shock or a malfunction.
▶Place the belt cover on top of the machine.
▶Use both hands when bending the machine backwards or returning it to the normal position.
Using only one hand can lead to severe hand injuries due to the weight of the machine.
To Next Page
