3-22)
Setting the angle of reverse rotation after trimming [
O
nly applied for SPS/
B/
C-Series]
…80
3-23) Setting output port [Only applied for SPS/C-Series] ……………………………… 81
3-24)
Setting time delay when output port is being used [
O
nly applied for SPS/C-Series]
…84
3-25) 3rd Thread Adjusting Device (TR3) Setting ………………………………………… 85
3-26) Basic Clamp Position Setting …………………………………………………………… 88
4) Pattern Data General Function ……………………………………………………………… 89
4-1) Checking and deleting the pattern number …………………………………………… 89
4-2) Making a copy the pattern to another number or diskette ………………………… 90
4-3) Function to copy saved patternS from interior memory to USB flash drive …… 91
4-4) Pattern information displaying function ………………………………………………… 92
4-5) Change of parameter related to general sewing ……………………………………… 93
4-6) Initialization of parameter related to general sewing ………………………………… 94
4-7) System program update …………………………………………………………………… 95
4-8) Confirmation for version of system program ……………………………………………96
4-9) Bobbin counter setting by design………………………………………………………… 97
4-10) Saving in the Internal Memory after Creating Pattern Designs…………………… 99
5. High Operating Method …………………………………………………………………100
1) Understanding the function of machine test ………………………………………………… 100
1-1) Encoder test ………………………………………………………………………………… 100
1-2) Step motor-main shaft motor test (X-Y Main Test) ……………………………… 100
1-3) Main motor test …………………………………………………………………………… 101
1-4) Interrupt test ……………………………………………………………………………… 102
1-5) PWM test…………………………………………………………………………………… 102
1-6) LCD test …………………………………………………………………………………… 103
1-7) Keyboard test ……………………………………………………………………………… 104
1-8) Input 0 test ………………………………………………………………………………… 104
1-9) Input 1 test ………………………………………………………………………………… 105
1-10) Input 2 Test ……………………………………………………………………………… 106
1-11) Input 3 Test ……………………………………………………………………………… 106
1-12) Input 4 Test [Only applied for SPS/C-Series] ……………………………………… 107
1-13) Input 5 Test [Only applied for SPS/C-Series] ……………………………………… 107
1-14) Input 6 Test [Only applied for SPS/C-Series] ……………………………………… 108
1-15)
Lower Shaft Encoder Test (Encoder1 Test) [Only applied for SPS/C-Series]
………… 109
1-16) Solenoid Test ……………………………………………………………………………… 109
1-17) Output 4 Test [Only applied for SPS/C-Series] …………………………………… 110
1-18) Output 5 Test [Only applied for SPS/C-Series] …………………………………… 111
1-19) Other output ports[only applied for SPS/C-Series] ………………………………… 111
1-20) Manual operation test of step motor (XY Jog Test) ……………………………… 112
1-21) Origin Test ………………………………………………………………………………… 112
1-22) Jump Test ………………………………………………………………………………… 113
1-23)
Communication test between the main shaft board and the CPU/IO board (Async Test)
…… 113
6. Description on Parameter Related to General Sewing Operation ………………115
1) Function no. related pattern programming …………………………………………………… 164
2) Pattern chart……………………………………………………………………………………… 166
3) Parameter number related to general sewing ………………………………………………… 167
4) Error list ………………………………………………………………………………………… 172
5) SPS/A/B/C-Series block diagram……………………………………………………………… 174
6) Table drawing …………………………………………………………………………………… 178
7) Basic Manual …………………………………………………………………………………… 179
7. Emergency Recovery………………………………………………………………………181
1) Emergency recovery when problems occur in flash memory ……………………………… 181
2) User's emergency self-restoration and operating program installation …………………… 182
8. Special Functions …………………………………………………………………………183
1) Auto Call Function ……………………………………………………………………………… 183
2) Design auto call through handy barcode……………………………………………………… 191
9. Parameter save function …………………………………………………………………194
1) Parameter Write ………………………………………………………………………………… 194
2) Parameter Read ………………………………………………………………………………… 195
