64
<Function Code>
043:SYMMETRY X<
044:SYMMETRY Y
045:SYMMETRY P
F. After pressing CODE key, if you know the
function number related to pattern programming,
input three-figure digit number 043 and if you
do not know the number, press ENTER key.
Then, after moving to “043:SYMMETRY X”
by using direction key , press ENTER key.
-X-axis symmetry is Function Code 043
-Y-axis symmetry is Function Code 044
-Optional point symmetry is Function Code 045
CURVE
X:00000A N:00023
Y:00059A
Function Code?
G. Confirm if symmetrical shape was made properly
by using FORW and BACK key.
3-10) Condensed Sewing Stitch Inserting Function
It is the function to prevent stitches from being untangled by making stitch width condensed in sewing
start part and sewing end part of pattern data.
A. Insert USB flash drive containing the pattern to
insert condensed sewing stitch.
B. Press MODE key.
Initial Condensed Sewing 3 stitches
Sewing Start Point
Sewing End Point
Sewing Start Point
Sewing End Point
Initial Condensed Sewing
End Condensed Sewing 3 Stitches End Condensed Sewing
3.0mm 0.5mm
3.0mm 0.5mm
< Before Condensed Sewing Insertion > < After Condensed Sewing Insertion >
C. After moving to “2. Program” menu by using
direction key , press ENTER key. At this
time, the upper feed plate comes down and
moves to the original point.
ORIGIN
X:00000A N:00000
Y:00000A
Function Code?
