SunStar SPS/A Series

Organization of the Pattern S/M Model
Series
A: Motor belt-type
B: Motor direct drive-type
SunStar
Pattern
System
Sewing Area
SPS/B-1306-H S-10
X : 130mm
Y : 60mm
Feeding Frame
Type
Stitch Type
Material Type
󳣑 Pattern Model
A : Belt Type
H : Drive Type
󳣑 Sewing Area
1306 : X(130mm), Y(60mm)
1507 : X(150mm), Y(70mm)
1310 : X(130mm), Y(100mm)
1811 : X(180mm), Y(110mm)
2516 : X(250mm), Y(160mm)
5030 : X(500mm), Y(300mm)
󳣑 ApplicationSewing Area
G:General Material
H:Heavy Material
󳣑 Stitch Type
S:Standard Stitch
P:Perfect Stich
󳣑 Feeding Frame Type
10 : Magnet-Driven Feeding Frame
20 : Pneumatic Monolithic Feeding Frame
21 : Pneumatic Monolithic Feeding Frame with Two Step
Stroke Device
22 : Pneumatic Separately-Driven Feeding Frame
(22-1 : Pneumatic Separately-Driven Feeding Frame wiht
Two Step Stroke Device
23 : Pneumatic Separately-Driven Feeding Frame with
Inverting Clamp Device
