Sunstream FL6 HOVERCOVER - Height Adjustment; Height Adjustment - Position A; Height Adjustment - Position B

Height of the HoverCover is adjusted with the Telescoping Linkages. The HoverCover
has four preset positions incrementing every six inches. Figures below show the height
clearances for the HoverCover.
Dimension “A” is the distance between the bottom of the boat and the frame of the Hover-
Cover when the lift is in the up position.
Dimension “B” is the distance between the water and the HoverCover frame when the lift
is in the down position. The HoverCover can be set to the following range of heights
shown below.
HEIGHT ADJUSTMENT
** Maximum and minimum heights are calculated from a boat model with a 21-degree dead-rise hull
***Assumes curved windshield. Actual height will be determined by shape of boat.
MAXIMUM HEIGHT - 73"/185cm
MINIMUM HEIGHT** - 55"/140cm
A
B
MAXIMUM HEIGHT - 102"/259cm
MINIMUM HEIGHT** - 84"/213cm
MAXIMUM BOAT HEIGHT***
102"/221cm
