6.2.МodelPS1-withonecoil
PS 1
150
PS 1
200
Capacity L 150 200
Height H,mm 1310 1710
Minimalvercalclearance mm 1400 1780
Diameterwithoutinsulaon/withinsulaon D,mm Ø400/500 Ø400/500
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95
Operangpressure/Max.coiltemperature bar/
0
C 16/110 16/110
Recommendedboilersize,connectedtobuertank kW 6-10 6-10
Weight kg, 56 74
SleeveforElectricheangelement В,mm,Rp1
1/2”
755 995
Heatcarrier С1,mm,Rp1
1/2”
185 185
Heatcarrier С2,mm,Rp1
1/2”
185 185
Heatcarrier С3,mm,Rp1
1/2”
485 725
Heatcarrier С4,mm,Rp1
1/2”
485 725
Heatcarrier С5,mm,Rp1
1/2”
885 1165
Heatcarrier С6,mm,Rp1
1/2”
885 1165
Heatcarrier С7,mm,Rp1
1/2
” 1125 1525
Heatcarrier С8,mm,Rp1
1/2
” 1125 1525
Sensorsleeve А1,mm,Rp1/2” 185 185
Sensorsleeve А2,mm,Rp1/2” 485 725
Sensorsleeve А3,mm,Rp1/2” 885 1165
Sensorsleeve А4,mm,Rp1/2” 1125 1525
Airventsleeve F,mm,Rp1
1/2
” 1310 1710
CoilcapacityS1 S1L 6.8 9.9
HeatexchangesurfaceS1 S1m
2
1.1 1.6
Inlet/OutletLowercoilS1 S1i/S1o,mm,Rp1” 705/185 1125/805
