INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL
SPBM series -
Inlet/Outlet arrangement: 90 angle
degrees for easy and convenient
installaon.
Possibleinstallaoninthecornerofboiler
room.
Models SPBM - without coil
Models SPBM R - with one coil
Models SPBM R2 - with two coils
Product features:
- Oponal removable insulaon with
thickness 100mm and outer casing of
PVC,RAL9006color.
-Insulaontypeavailableforallmodels:
soPU,eece.
- Dividing plate (Separator). Distribuon
plate(waterstracaonunit).
-Primercoatedontheoutsideofthetank
-Upto5pcs.Rp½”sensorsleeves
Upto13pcs.Rp1”orRp1½”inlet/outlet
sleeves -connecons to heang boilers,
indirect heang of domesc hot water
(DHW)andsolarsystem
Heat exchanger coil /coils (PBM R and
PBMR2)
-Oponal kit for electric heang with
nominal power 3kW, 4.5kW, 6kW or
7.5kW
2.1.Insulaonandoutercasing
* PBM-H/ SPBM-H series – Rigid PPU
Capacity
Buertank,L
Insulaontype
150, 200,
300, 500, 800, 1000, 1500,
2000, 2500, 3000, 5000
Rigid PPU 50mm
Soft PPU 100 mm
removable
The quality of the insulaon of a
water heater is a key factor for its heat
conservaon capability and energy
eciency.
All Buer tanks have a high eciency
insulaon (DIN 4753, part 8) and outer
casingwithRAL9006.
2.2. Connecting of safety relief valve
to buffer tank
1. Heating installation.
2. Tee.
3. Safety (relief) pressure valve.
4. Heat-carrier inlet.

Stop (Shut-off) valves should
never be installed between a
safety (relief) valve and the tank.
It is recommended once a year to
check the operation of the safety
valve.
2.3. Thermometer.
Amicroscopicview
ofhardpolyurethane
