SUNTEC SP500C Pro - Installation and Specifications; Installation Methods; Technical Specifications

Installing your dehumidifier
How to install the dehumidifier on the wheels?
Step 1: Lift up the dehumidifier and let it sit on
the wooden box as show on figure below.
Step 2: Take out the wheels from the accessory
bag and screw those wheels into the screw
thread on the base.
Step 3: Put the dehumidifier on the flat ground.
Step 4: Adjust the wheels height according to the
ground condition.
How to install the dehumidifier on the ground?
Step 1: Lift up the dehumidifier and let it sit on
the wooden box as show on figure below.
Step 2: Take out the floor mounted brackets from
the accessory bag and screw those brackets into
the screw thread on the base.
Step 3: Put the dehumidifier on the flat ground.
Step 4: Adjust the brackets height according to
the ground condition.
Specifications
Model
SP500C Pro
SP1000C Pro
SP1500C Pro
Water Removal
(30°C/80%RH)
50L per day
100L per day
150L per day
Operating Temp.
Range
1° - 40° C
1° - 40° C
1° - 40° C
Operating
Humidity Range
10% to 90% RH
10% to 90% RH
10% to 90% RH
Compressor /
Refringent
Rotary / R410A
Rotary / R410A
Rotary / R410A
Power
Consumption
720Watt
1500Watt
2050Watt
Voltage / Cycle
220~240V/50Hz
220~240V/50Hz
220~240V/50Hz
Ampere
3.1A
6.5 Amps
8.9 Amps
Rated Air Flow
500 m
3
/h
800 m
3
/h
900 m
3
/h
Noise Level
42dB(A)
48dB(A)
48dB(A)
Installation/
mobility
Mobile/ Floor Mount
/ Wall Mount
Mobile/ Floor Mount
/ Wall Mount
Mobile/ Floor Mount
/ Wall Mount
Touch-pad
control panel
Yes
Yes
Yes
Remote Control
Yes
Yes
Yes
Defrost Type
Hot-gas bypass
Hot-gas bypass
Hot-gas bypass
Air Filter
Washable
Washable
Washable
Housing
Hard Plastic
Hard Plastic
Hard Plastic
Drain Hose
Length
2m
2m
2m
Cable Length
3m
3m
3m
W x D x H
65 x 27 x 55cm
89 x 29 x 76cm
100 x 33 x 80cm
Use Weight
35kg
56kg
71kg
Specifications are subject to change without notice. Some values are approximate.
