Select 207 XLS User / Installation Instructions Page 8 of 8
Programmer will plug directly onto existing wall-plates of the following programmers without any rewiring, just follow
the installation instructions.
MANUFACTURER MODEL MANUFACTURER MODEL
ACL LP112, LS241, LS522, LS722 LANDIS & GYR RWB2, RWB2.9, RWB 102,
LP241, LP522, LP722 RWB200, RWB252, RWB20
RWB40
DANFOSS FP75, FP15, CP75, CP15 POTTERTON MINIMINDER
DRAYTON TEMPUS 3 & 4 & 7 GLOW-WORM MASTERMIND
SUNVIC SELECT 207
Otherwise fit new wall-plate supplied, and refer to wiring interchange guide below.
WIRING INTERCHANGE GUIDE
When replacing any of the below with your Sunvic SELECT 207XL programmer, fit new wall-plate supplied and follow
the connection details shown. Whilst every effort is made to ensure accuracy of the instructions given, you will
appreciate that discrepancies may occur, due to various reasons outside of our control.
Make Model Terminals
Sunvic SELECT 207XL N L 1 2 3 4
SP100 & SP50 N L 1 4 2 5
SP2 N L 1 4 3 6
Satchwell Libra & DHP2201 1 2 8 5 6 3
Satchwell ET1401 & ET1451 1 2 8 5 7 4
Honeywell ST699B & C N L 7 4 6 3
ST499A N L - - 6 3
ST6300 & ST6400 N L 1 2 3 4
ST7100 N L 7 4 8 5
ACL MP 2 1 - - 6 10
FP 2 1 8 11 6 10
2000 N L hw off ch off hw on ch on
Randall 922 & 972 N L 1 4 3 6
4033 7 6 5 3 4 2
701 N L - - 3 1
702 N L 4 2 3 1
102 5 6 - - 1 2
3060 & 3020P 1&7 6 - - 4 2
3033 1&7 6 5 3 4 2
SET2 & SET5 N L 3 6 1 4
TSR3+3 3&6 7 2 5 1 4
MK11 R6 3 1&2 - - 4 5
TSR2P 3 1 - - 5 7
Sangamo 410F1 & F9 & F414 4&5 3&6 2 7 1 8
M5 4 3 - - 1 6
Potterton EP2000 & EP3000 N L 1 2 3 4
Horstmann Amethyst 7 & 10 2 1 4 6 5 7
Coral 2 1 - - 8 4
Diadem N L 3 6 1 4
Diamond N L - - 2 4
Gem 2 1 6 9 4 7
Leucite 2 1 8 4 3 6
Smiths Centroller N L 1 2 3 4
Switchmaster 400 & 600 N L - - 3 1
805 & 900 & 9000 N L 4 2 3 1
Thorn Microtimer N L 7 4 6 3
Towerchron T2002 N L - - HW CH
T2000 & T2003 N L HW OFF CH OFF HW ON CH On
Direct plug-in upgrade for existing programmers
