Sunvic TL ONE - Page 7

TL ONE
Installation Guide 7
Always install the thermostat at least 50 cm.
from windows and doors.
Do not place the thermostat in a way that
it will be exposed to direct sunlight.
Follow the steps below to mount the thermostat:
1. Open the thermostat:
devireg™550
3
5
6
2
4
20
30
40
50
• Press the release tab in the bottom of the ther-
• Carefully detach the front cover.
• Carefully detach the frame.
