TL ONE
Installation Guide8
2. Connect the thermostat according to the connection
diagram.
IP31
-10T30
D531
Mains
220-240V~
Max. Load
15 (1) A
N L
N
LOAD
L
LOAD
9 еквонатсу оп овтсдовокуР
The screen of the heating cable must be connected
to the earth conductor of the power supply cable by
using a separate connector.
Note:
3. Mount and reassemble the thermostat.
• Fasten the thermostat to a socket or an exterior
wall box by driving the screws through the holes
in each side of the thermostat.
• Install the frame and front cover in the reverse
order of disassembly.
4. Turn on the power supply.
