Supco DAVM+ User Manual

3
2-2 Measurement Specifications
Measurement Range Resolution
Air velocity ft/min 80 to 5,910 ft/min 1 ft/min
m/s 0.4 to 30.0 m/s 0.1 m/s
km/h 1.4 to 108.0 km/h 0.1 km/h
MPH 0.9 to 67.0 mile/h 0.1 MPH
knots 0.8 to 58.3 knots 0.1 knots
Temperature 32 to 122 °F 0.1 °F
(thermister) 0 to 50 °C 0.1 °C
Measurement Range Resolution
Air flow CFM 1,908,400 CFM 0.001 to 100
cube feet/min CFM
CMM 54,000 CMM 0.001 to 1
cube meter/min CMM
Measurement Range Resolution
Humidity % RH 10 to 95 % RH 0.1 % RH
Temperature 32 to 122 °F 0.1 °F
( thermister) 0 to 50°C 0.1 °C
Measurement Range Resolution
Light Lux 0 to 2,200 Lux 1 Lux
1,800 to 20,000 Lux 10 Lux
* auto range Ft-cd 0 to 204.0 Fc 1 Ft-cd
170 to 2,000 Fc 1 Ft-cd
Measurement Range Resolution
Temperature (Type K) -148 to 2,372 °F 0.1 °F
Optional -100 to 1,300 °C 0.1 °C

Supco DAVM+ Specifications

General

Brand	Supco
Model	DAVM+
Category	Measuring Instruments
Language	English
