2
TECHNICAL SPECIFICATIONS
Main Use
SuperHandy electric power dolly is compact in structure and convenient in operation. It is used
for towing trailers, RVs, etc. equipped with ball head couplings. It has the functions of forward,
backward and steering, and can achieve movement over short distances or in compact spaces.
Product packaging list
MAIN COMPONENTS
SKU
Description
Power supply
Power
Maximum bearing capacity
Ball head specification
Size
Net weight/Gross weight
GUO092
Electric Power Dolly
DC24V,7Ah
800W
Trailer Weight: 1620kgs/3600Lb
Tongue Weight: 270kgs/600Lb
2"
50"x25"x38" (1262x632x950mm)
112/126lbs (51/57 kg)
1. Handle bar kit
2. Connecting rod
3. Adjusting lever kit
4. Frame & Power components kit
5. Swivel wheels x2
6. Hitch ball kit
7. Charger
8. Accessory pack (M10 nut 2PCS,
M10x55 bolt 2PCS, M10x16 bolt 2PCS,
M8x16 screw 2PCS, M8 nut 2PCS,
wheel cover 2PCS, pin assembly 5/8-in
4PCS)
9. 13-inch rear wheel x2
