Adjustment
Description
Value
RECEIVER
T8 RF Input
T9 RF Input
T10 RF Input
T11
1. IF
10,7MHz
T12 1. IF 10,7MHz
T13 AM IF 455kHz
T14 AM Detector 455kHz
T6 SSB IF 455kHz
T7 SSB Detector
T16
FM Discriminator
TRANSMITTER
T1 PLL Output to Converter 37.660 - 38.100MHz for CEPT
T2 PLL Output to Converter 37.660 - 38.100MHz for CEPT
T3 Transmitter Output 26.965 - 27.405MHz for CEPT
T4 Transmitter Output 26.965 - 27.405MHz for CEPT
T5
Transmitter Output
26.965 - 27.405MHz for CEPT
L16 Transmitter Output 26.965 - 27.405MHz for CEPT
CT8 Transmitter Output USB/LSB 26.965 - 27.405MHz for CEPT
CT9 Transmitter Output USB/LSB 26.965 - 27.405MHz for CEPT
RV2 Bias Q8
RV11 AM/FM Output Power 10 Watt
METER
RV4 RF Power Meter
RV8 RF S-Meter SSB (USB/LSB)
RV9 RF S-Meter AM/FM
.
RV1 FM Modulation +/- 2kHz
RV6 SSB Modulation 18 Watt p-p
RV11 AM Modulation 90%
RV5 Carrier at SSB Adjust for NO Carrier
