SUPER STEAM X5 53
HOW TO ASSEMBLE HAND-HELD STEAMER
ton on the Extension Hose with the designated hole on the Window
Cleaning Tool Frame and then push in the
Extension Hose unl it locks in place (as illustrated in Fig. 3a &
3b).
Coral Cloth onto the designated hooks on the Window Cleaning
Tool Frame and pull up the drawstring to secure the Coral Cloth in
place. NOTE: Do not cover the squeegee blade. Make sure to aach
the Coral Cloth to all hooks on the Cleaning Tool Frame to prevent
slipping or falling from the frame during use (as illustrated in Fig. 2a,
2b & 2c).
GARMENT STEAMING TOOL
4. To use the Window Cleaning tool as a Garment Steamer, in-
stall the Microber Cloth or the Lint Cloth over the Window Clean-
ing/Garment Steamer Tool (as illustrated in Fig. 4a, 4b & 4c).
5. Aach the Window Clean-
ing/Garment Steamer Tool to the
Extension Hose as follows: Align
the lock buon on the Extension
Hose with the designated hole on
the Window Cleaning/Garment
Steaming Tool Frame and then push the Extension Hose unl it locks
in place (as illustrated in Fig. 5a)ed in Fig. 4a, 4b & 4c).
DUSTER
6. Install the
cleaning Coral Cloth
onto the Duster
Frame (as illustrated
in Fig. 6a & 6b).
