Super Steam X5 - HOW TO ASSEMBLE THE OPTIONAL ACCESSORIES

SUPER STEAM X552
HOW TO ASSEMBLE THE OPTIONAL ACCESSORIES
1. Insert the designated end of
the Extension Hose into the desig-
nated hole in the Main Unit unl
it locks in place with the Lock
Buon on the Main Body (you
will hear a clicking sound) as
illustrated in Fig. 1a, 1b & 1c.
Make sure that the Extension
Hose is securely locked into place before usage.
Remove the Mop Head by pressing the Lock Buon on the Main
Body or remove the Jet Nozzle following the same procedure.
WINDOW CLEANING TOOL
2. Loosen up the drawstring on the Coral Cloth and install the
Coral Cloth onto the designated hooks on the Window Cleaning Tool
Frame and pull up the drawstring to secure the Coral Cloth in place.
NOTE: Do not cover the squeegee blade. Make sure to aach the
Coral Cloth to all hooks on the Cleaning Tool Frame to prevent slip-
ping or falling from the frame during use (as illustrated in Fig. 2a, 2b
& 2c).
3. A t t a c h
the Window
Cleaning Tool to
the Extension
Hose as follows:
Align the lock but-
