SuperATV Roof - Rear Section Mounting

Rear
- JoinReartoBracketwithhardwareshown.FlatSealwillinstallbetweencomponents. - Install Clamps to Rear with hardware shown.
M6 Nut
Large Clamp
5 each
Bracket
Flat Seal
M6 x 25mm
2 each
Clamp
M6 x 20mm
4IN-ROOF-K-TRX4-003
Large Clamps only: - RemovescrewsfromClampsandopen. - Install Flat Seal to areas shown.
Flat Seal
Small Clamp x 3
Large Clamp
Sealing Washer
M6
Sealing Washer#14
