SuperATV Roof - Front Section Mounting

5
IN-ROOF-K-TRX4-003
Large Clamps only: - RemovescrewsfromClampsandopen. - Install Flat Seal to areas shown.
Flat Seal
- JoinFronttoBracketwith
hardware shown.
(Driver Side)
M6 Nut
5 each
M6 x 25mm
Front
Sealing Washer
M6
- Install Clamps to Front with hardware shown.
2 each Clamp
M6 x 20mm
Front
Small Clamp x 2
Large Clamp x 2
Large Clamp x 2
Sealing Washer
#14
