Superior Electronics SMART iCM003 - Page 43

802.11n HT-20 (6.5Mbps) Mode
Channel
Test
Condition
Bursts
Power
(dBm)
Limit (dBm) Test Result
Low
NTV 15 11.63 20 Compliant
LT/NV 15 10.96 20 Compliant
HT/NV 15 10.33 20 Compliant
Middle
NTV 15 11.52 20 Compliant
LT/NV 15 10.83 20 Compliant
HT/NV 15 11.43 20 Compliant
High
NTV 15 11.63 20 Compliant
LT/NV 15 10.49 20 Compliant
HT/NV 15 10.28 20 Compliant
802.11n HT-40 (13.5Mbps) Mode
Note: 1. Cable loss and antenna gain was combined in the calculated result.
Channel
Test
Condition
Bursts
Power
(dBm)
Limit (dBm) Test Result
Low
NTV 15 11.17 20 Compliant
LT/NV 15 10.68 20 Compliant
HT/NV 15 10.21 20 Compliant
Middle
NTV 15 11.76 20 Compliant
LT/NV 15 10.63 20 Compliant
HT/NV 15 10.17 20 Compliant
High
NTV 15 10.86 20 Compliant
LT/NV 15 10.49 20 Compliant
HT/NV 15 10.19 20 Compliant
