PARTS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on Page 23 of this manual.
KEY NO. CATALOG NO. DESCRIPTION 36" Models 42" Models QTY
1 J6811 MICRO SWITCH • • 1
2 J4667 SCREW, #10 X 5/8 PH AB BLK • • 2
3 J6976 DIVERTER, DRAFT GL3000 • 1
J6977 DIVERTER, DRAFT GL4000 • 1
4 J3946 RETAINER, AIR ROD • • 1
5 J3947 RETAINER, DAMPER ROD • • 1
6 F2880 EXTENSION DEFLECTOR • 2
F2881 EXTENSION DEFLECTOR • 2
7 J6918 SPACER, TOP 42GC17 • • 4
8 J6905 CLIP, SPRING G36GC16-1 • • 2
9 J3952 SEPARATOR, AIR • 1
J4060 SEPARATOR, AIR M42 • 1
10 J4955 BUSHING DBL INSUL • • 2
11
See Page 26
LEFT REFRACTORY 1
12
See Page 26
RIGHT REFRACTORY 1
13
See Page 26
REAR REFRACTORY 1
14
See Page 26
BOTTOM REAR REFRACTORY 1
15
See Page 26
BOTTOM FRONT REFRACTORY 1
16 J6802 STRAIN RELIEF • • 1
17 H6243 SWITCH, HIGH LIMIT 290 DEG F • • 1
18 J3975 ROD, SCREEN FORMED 36" C.C. • 2
J4084 ROD, SCREEN FORMED 42" C.C. • 2
19 J6903 STOP, DOOR G36GC17-2 • • 1
20 J3976 COLLAR, TRANSITION 6" B-VENT • • 1
21 J3980 ASSY, AIR KIT DOOR 36" • • 1
22 J6900 PLATE,OUTSIDE AIR COVER 36E44-6 • • 1
23 J3992 DEFLECTOR, SMOKE • 1
J4081 DEFLECTOR, SMOKE • 1
24 J6895 RETAINER, REFRACTORY 36E28 • • 2
25 J4054 GRATE, ASSEMBLY • 1
J4055 GRATE, ASSEMBLY • 1
26 J4048 PAN, BURNER • 1
J4049 PAN, BURNER • 1
27 J4053 TUBE, BURNER • 1
J4083 TUBE, BURNER • 1
28 J4051 BRACKET, BURNER • • 1
29 J4094 SHIELD, PILOT • 1
J4095 SHIELD, PILOT •
30 J7320 CLIP, BURNER • • 1
31 J4769 NUT 10-24 HEX • • 1
32 J4605 SCREW 10-24X1/2 PPH MS BLK. OX • • 1
33 J7221 HOLDER, INJECTOR (NG) • • 1
J7222 HOLDER, INJECTOR • • 1
34 J7203 INJECTOR (NG) #31 • 1
J7204 INJECTOR (NG) #30 • 1
J7220 INJECTOR, LP #52 • 1
J7217 INJECTOR, LP #50 • 1
35 J4116 PILOT,NG#51 TP,CONV.36 199.761 • • 1
J4120 PILOT,LP#30 TP,CONV.36 199.767 • • 1
36 J4121 PILOT INJECTOR, NG #51 • • 1
J4122 INJECTOR, LPG #30 • • 1
37 J4489 SCREW #8 X 3/8 PPH B ZINC • • 2
38 H6244 VALVE, NAT, DEBIE FIXED, SIT (0.820.618) • • 1
H3142 VALVE,PROP,DEBIT FIXE, SIT (0.820.617) • • 1
39 J4044 BRACKET, VALVE • • 1
40 J3546 PIEZO IGNITER, WITH NUT, 097159-04 • • 1
41 J4533 GAS LINE FLEX 18" W/SHUT OFF • • 1
42 J6893 COLLAR, CHIMNEY STARTER, 36C19-1 • • 1
43 J4098 HARNESS, WIRE, M36 • • 1
44 J4099 HARNESS, WIRE, JUMPER • • 1
45 J4956 NUT, PUSH-ON .765 X .445 X .011 BLCK • • 2
46 J5666 SCREEN, 22 X 21 • 2
J4085 SCREEN, 26H X 24.5 • 2
PARTS AVAILABLE NOT SHOWN
J7274 VERMICULITE, PLN BAG , #1.00 • • 1
J7275 EMBER PAN MATERIAL - 0.4# PLAIN BAG • • 1
80L42 VOLCANIC STONE, BAG, 2.50# LB • • 1
