INSTALLATION
Continued
INSTALLING OPTIONAL BLOWER
ACCESSORY
NOTICE: The rebox identica-
tion label (including model num-
ber, serial number, clearances,
etc.) is located in the right side
screen pocket area on the front
of the rebox. See Figure 19,
page 17.
NOTICE: If a log set is installed
in the rebox, disconnect log
set from gas supply and remove
from rebox. Contact a qualied
service person to do this.
Note: Appearance of rebox may vary de-
pending on model.
There is one (1) blower accessory option
for use with this replace. Blower accessory
model BK . Model BK is a rotary squirrel cage
type blower with magnetic attachment and
variable speed control.
Wiring Instructions
1. Remove electrical cover plate with bush-
ing from replace by removing 2 sheet
metal screws as shown in Figure 11, page
13.
2. Slide power source wiring through electri-
cal bushing opening and electrical cover
plate and make all necessary connec-
tions.
3. Slide all wiring connections in electrical
housing as shown in Figure 11, page 13.
4. Secure electrical cover plate with screws
previously removed.
Note: Electrical housing and cover plate have
sharp edges. Wear protective gloves.
Figure 10 - Location of Knockout for
Gas Line
1/2" Thick Liner
Side View
Firebrick Side Wall
Knockout
Remove
This Area
USING OPTIONAL FIBER PANELS
There is a gas knockout in each side panel
for the gas line to feed through. Determine on
which side the gas connection will be located.
Using a utility knife or cutting blade, remove
the identied gas knockout.
CAUTION: Do not use ex-
cessive force to remove the
knockout. Too much force may
damage the ber panel.
WARNING: DO NOT FILL THE
SPACES AROUND THE FIRE-
BOX WITH INSULATION OR
OTHER MATERIALS.
WARNING: FRAMING MAY BE
PLACED OR REST AGAINST
FIREPLACE SPACER, HOW-
EVER, FRAMING MUST NEVER
BE NOTCHED.
WARNING: DO NOT ALTER,
CUT, OR MODIFY FIREPLACE
SPACERS.
