5
VOLUME
E205U
Unit:mm/inch
A
C
B
D
USB Power Indicator
When it is lit up, it means the USB connec-
tion is done and E205U get the power from
USB interface.
Headphone Volume Control
Pop-out level control to adjust the overall
volume of the Headphone output.
Headphone Output Jack
1/8-inch (3.5mm) stereo jack for connect-
ing headphones or studio monitors.
USB connector
E205U involves a USB B-type connector,
it is allowed to connect to laptop with USB
A-type jack.
FUNCTION DESCRIPTION
A
B
C
D
To Next Page
