① CH-B Antenna socket
② CH-B Audio balanced output: Suitable for long-distance connection to reduce the
noise derived from the cable effectively
③ Power socket: DC12V 1000mA power input socket. The central electrode of the
socket is connected to the positive pole
④ Audio mixed output: Mixing the signal from A and B channels into one output
⑤ CH-A Audio balanced output: Suitable for long-distance connection to reduce the
noise derived from the cable effectively
⑥ CH-A Antenna socket
REAR PANEL DESCRIPTION
① ② ③ ④ ⑤ ⑥
