Motherboard Features
CPU
• Intel® Xeon® E3-1200 v5 and 6th Gen Core™ i3, Pentium and Celeron processors in an LGA 1151 (H4) socket. 80W
max TDP.
Memory
• Four (4) 288-pin DIMM slots support up to 64 GB of SDRAM 72-bit DDR4 unbuffered ECC 2133/1866/1600/1333MHz
memory.
DIMM Size
• 16GB, 8GB, and 4GB, up to 64GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel® PCH C236
Expansion Slots
• One (1) PCI Express 3.0 x4 in x8 slot (PCH Slot 4)
• One (1) PCI Express 3.0 x8 (CPU Slot 5)
• One (1) PCI Express 3.0 x8 in x16 slot (CPU Slot 6)
• One (1) M.2 Mini PCI Express 3.0 x2 connector
Network
• Dual Gbe LAN ports (2x i210) for LAN1/LAN2
• Quad Gbe LAN ports (4x i210) for LAN1-LAN4 (X11SSH-LN4F)
• One (1) dedicated IPMI LAN located on the rear I/O panel
Baseboard Management Controller (BMC)
• ASpeed 2400 Baseboard Controller (BMC) supports IPMI 2.0
Graphics
• Graphics controller via ASpeed AST2400 BMC
I/O Devices
• Serial (COM) Port
• One (1) front accessible serial port header (COM2)
• One (1) serial port on the rear I/O panel (COM1)
• SATA 3.0
• Eight (8) SATA 3.0 ports supported by Intel PCH (I-SATA0-ISATA7)
• Two (2) SuperDOM connectors (I-SATA0 & I-SATA1)
• RAID (PCH) • RAID 0, 1, 5, and 10
• Video (VGA) Port • One (1) VGA connection on the rear I/O panel
Motherboard Features

Supermicro X11SSH-F Specifications

General

IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Maximum UDIMM memory	64 GB
Number of DIMM slots	4
Supported DIMM module capacities	4GB, 8GB, 16GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	1600, 1866, 2133 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	16 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2400
Processor socket	LGA 1151 (Socket H4)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor thermal power (max)	80 W
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Number of SATA III connectors	8
Trusted Platform Module (TPM) version	1.2
Motherboard chipset	Intel® C236
Motherboard form factor	micro ATX

Weight and Dimensions

Width	224 mm
