Super X13DEG-OAD User's Manual
Power Management
• ACPI power management
• S1, S4, S5 support
• Power button override mechanism
• Power-on mode for AC power recovery
• Power supply monitoring
System Health Monitoring
• Onboard voltage monitoring for +12V, +5V/+5V standby, +3.3V, +3.3V standby, Vcore, and Vmem
• Onboard temperature monitoring for CPU, VRM, LAN, PCH, system, and memory
• 7+1 CPU switch phase voltage regulator
• CPU thermal trip support
• Platform Environment Control Interface (PECI)
Fan Control
• Fan status monitoring via BMC connections
• Single zone cooling
• Low-noise fan speed control
• Three 4-pin fan headers
System Management
• Server platform service
Firmware Integrity/System Security
• TPM (Trusted Platform Module) support
• RoT (Root of Trust) support to protect rmware security by detecting critical data corruption, and restoring platform integrity
LED Indicators
• Power LED
• UID/remote UID
• LAN activity LED
• BMC/CPLD rmware LED
Dimensions
• 15.00" (W) X 17.00" (L) (381.00mm x 431.8mm)
Note 1: The CPU maximum thermal design power (TDP) is subject to chassis and
heatsink cooling restrictions. For proper thermal management, please check the chas-
sis and heatsink specications.
Note 2: For BMC conguration instructions, please refer to the Embedded BMC Con-
guration User's Guide available at http://www.supermicro.com/support/manuals/.
