24
Super X13DEG-OAD User's Manual
2. The CPU Carrier
Carrier Bottom View
Carrier Top View
Carrier E1A
Carrier E1C
Carrier E1B
Pin 1
Pin 1
Pin 1
= Cutout = CPU Key
= Pin 1
CPU Key
CPU Key
CPU Key
= Cutout = CPU Key
= Pin 1
