Chapter 2: Installation
3. Heatsink
Note: Exercise extreme care when handling the heatsink. Pay attention to the edges
of heatsink ns, which can be sharp! To avoid damaging the heatsink, please do not
apply excessive force on the ns.
Air Flow Direction
Air Flow Direction
1U Heatsink
2U Heatsink
4U Heatsink and Heatsink Fan
