Chapter 2: Installation
2. First, turn over the CPU carrier and locate Pin 1 on the CPU and Pin 1 on the carrier.
Then, turn the processor over with component side (including the gold contacts) facing
up and locate CPU keys on the processor. Finally, locate the CPU keys and four latches
on the carrier as shown below.
CPU Key
CPU Key
Latch
Latch
Latch
Latch
Latch
Latch
Latch
Latch
CPU Key
CPU Key
CPU Key
CPU Key
Latch
Latch
Latch
Latch
SP XCC
SP MCC
Max Series (HBM)
